FORNO Orvieto 30'' Wall Mount Range Hood
FRHWM5094 30 Forno Orvieto Wall Mounted Range Hood Close Up
FRHWM5094 30 Forno Orvieto Wall Mounted Range Hood Control Panel

FORNO Orvieto 30” Wall Mount Range Hood

SKU: FRHWM5094-30 Category:
2 years in-house warranty
The Orvieto 30" STAINLESS STEEL Wall Mount RANGE HOOD helps create superior air quality with its powerful 600 CFM motor and four-speed touch control. The decorative stainless-steel crown molding adds an attractive finish to your kitchen design. The hood is made from high-grade stainless steel for durability, and boasts noise reduction technology for a quieter sound while in use. The included surface lights provide superior illumination and energy efficiency. Baffle filters capture heat, odors, gases and are dishwasher-safe making cleanup a breeze. This range hood is sure to be an asset in any kitchen.
+ View more videos
Features

Features

  • This wall mount rangehood is equipped with a powerful energy-efficient 600 CFM, designed to capture smoke, gases, steam and grease to keep your cooking area free of unwanted odors.
  • Filters are made of washable Stainless-Steel with a baffle design and designed to capture grease, smoke, odors and grease from the air.
  • 4 speed touch control for easy operation makes it simple to adjust the fan speed settings for air flow and ventilation levels according to your needs.
  • Two Surface lights offer bright illumination for cooktop surface.
  • The chimney includes a stainless steel decorative molding trim which adds an elegant, modern feel and a beautiful finishing touch.
  • Maximum power ventilation at a low noise level of 65dB allows you to enjoy an effective ventilation system without obtrusive noise disruption. Low setting delivers sound level of 44dB.

  Find online

Specifications

Specifications

Mount Type Wall Mount
Exhaust Method Ducted
Non-Ducted Filter Included No
Number of Filters Included 4
Recirculation Kit Included No
Duct Shape Round
Smudge-Resistant Finish No
Color Finish Stainless Steel
Primary Material Stainless Steel
Air Discharge Direction Vertically Upward
Exhaust Vent Location Roof / Wall
Power Source AC
Plug-In Yes
Voltage 120
Amperage 1.8
Filter Type Baffle
Washable Filter Yes
Dishwasher Safe Mesh or Baffle Filter Yes
Filter Material Stainless Steel
Maximum Air Movement (CFM) 600
Number of Speeds 4
Number CFM For speed level 1 275
Air flow For speed level 1 467
RPM For speed level 1 880
Noise Level For speed level 1 44
Number CFM For speed level 2 375
Air flow For speed level 2 637
RPM For speed level 2 1050
Noise Level For speed level 2 51
Number CFM For speed level 3 475
Air flow For speed level 3 807
RPM For speed level 3 1350
Noise Level For speed level 3 58
Number CFM For speed level 4 600
Air flow For speed level 4 1020
RPM For speed level 4 1510
Noise Level For speed level 4 65
Speed Control Type Touch Control
Maximum Sones 13
Minimum Sones 3
Noise Level 65
Lighting Included Yes
Adjustable Lighting Levels No
Number of Lights 2
Bulb Included Yes
Compatible Bulb Type LED
Number of Bulbs Included 2
Range Hood Chimney Extension Included Yes
Blower Type Interior unit
Chimney Short Kit Included Yes
Damper Included Yes
Crown Molding Included Yes
Glass Component Included No
Reversible Blower Capability No
Timer No
Heat Sensors No
Delay Shut-Off Yes
Remote Control Capable No
Remote Included No
Adjustable Height No
Round Duct Diameter 6
Minimum Height Above Cooktop 30
Maximum Height Above Cooktop 36

Dimensions

Overall Height - Top to Bottom (in) 45.16
Overall Width - Side to Side (in) 29.5
Overall Depth - Front to Back (in) 23.6
Overall Product Weight (lbs) 44

Warranty

Product Warranty Yes
Warranty Length 2 Years
Full or Limited Warranty Limited

Downloads

Specifications
Instruction Manual
Manuel d'instruction
Dimensions & Cut Out - Dimensions & Découpes

Videos

Presentation
Installation
